he magnetic mixer, a fully closed, non-leakage, non pollution
mixing, is installed at the bottom of tank. Because the sanitary
magnetic agitator is a non-contact transmission torque with no
transmission shaft, it is made by magnetic drive. The dynamic seal
was replaced by the static seal, which solved the problem that the
other shaft seal could not overcome the leakage. The whole material
and the stirring parts were operated in a sterile and sanitary
state. It is pharmaceutical, fine chemicals, cosmetics,
bioengineering and other industries ideal replacement products.
Application scope: mixing device for all kinds of reactors, mixing
tank and storage tank
Working condition: inflammable, explosive, easy to leakage, high
requirement on sealing
Technical parameter: working temperature:-20~220℃
Material: 316L or 304
Working pressure: -0.1~0.6Mpa
Model selection description: should know the change of viscosity
and density, working temperature and working pressure
Working characteristics
Sanitary magnetic mixers are designed for GMP modification in
pharmaceutical, bioengineering and food industries.
Good performance, reasonable structure, small volume and reliable
use.
The mixer is composed of inner magnetic steel, external magnetic
steel, isolation sleeve and driving motor.
It is applied to mixing device of stainless steel reactors and
mixing tanks.
All the contact materials of the magnetic agitator are made of
316l/304. The working principle of permanent magnetic coupling is
used to drive the operation of stirring shaft. The dynamic
mechanical seal is replaced with static mechanical seal, which
solves the unavoidable problem of mechanical seal. The magnetic
agitator produces a whirlpool by rotating, sucking dissolved powder
or liquid into the swirl and being quickly sucked into the stirring
impeller.
When the suction direction of the impeller rotates with the
impeller, the centrifugal force impinges different media into the
tank wall in the form of radiation from the outer diameter of the
impeller.
After hitting the tank wall, the liquid is sucked back to the
suction end of the impeller with impact force and rising cycle.
The constant moving agitation under the impeller thrust results in
homogenization, mixing, dissolution and dispersion.
Technical Data
| Material | Contact with the product parts | 316L |
| Non contact product parts | 304 |
| Viscosity | Max viscosity CP | 300CP |
| Pressure | Design pressure | -1~6bar |
| Temperature | Working temperature | -20~220℃ |
| Surface treatment | Internal surface finish | Ra0.4~0.6μm |
| Connection | Weld |
| Installation | Horizontal/vertical |
| Volume | 30L-30000L |
| Motor- decelerator | 0.37-18kw/110V-480V |
