The machine is widely used in pharmaceutical, food, chemical and
other industries to count and fill tablets, capsules, pills, food,
health care products and other materials.
Products Description
Automatic Capsule & Tablet counting machine
The electronic counting machine is a kind of light and compact
counting and filling equipment for solid particles. It adopts the
internationally advanced 8-channel vibration, computer control,
dynamic scanning counting, automatic bottle conveying and
photoelectric control. It is designed in strict conformance with
GMP standard and equipped with intelligent safety protection
devices such as system self-inspection, error warning and automatic
shutdown. As a high-tech material counting and filling machine, the
machine is widely used in pharmaceutical, food, chemical and other
industries to count and fill tablets, capsules, pills, food, health
care products and other materials.
automatic pill counting counter machine
The block bottle device on the passing bottle-track of the
conveying bottle system make the bottles which came from the
previous equipment stay in the bottling position,waiting to be
filled in.The medicine goes into the medicine container in order by
the vibration of the feeding corrugated plate.There is a counting
photoelectric sensor installed on the medicine container,after
counting of the medicine in the medicine container by the counting
photoelectric sensor, the medicine goes into the bottle in the
bottling position.
Main Features
1) Wide applicability:
Used for tablets (including abnormal tablets), capsules, gels
(including abnormal gels, transparent gels and opaque gels) pills
and most solid granules.
2) Anti-dust:
Using our own original high anti-dust sensor technology, the
machine works accurately with good stability in heavy dust
conditions.
3) Protect materials from harm
Feeding evenly with quiver, special patent filling part, no
breakage of the material.
4) Avoid the materials jam:
Hopper mouth of the special structure, to prevent the materials
jam, small mouth bottle can quickly bottling.(Optional)
5) Detection function:
No bottle will not count and fill. Automatically remove bottles of
filling abnormalities and a certain size broken tablets.
Self-diagnose errors and stop working to make alarm at errors.
| Main Technical Data |
| Model | LTEC-12 | LTEC-16 | LTEC-24 | LTEC-32 |
| Slide wheel | 12 Channels | 16 Channels | 24 Channels | 32 Channels |
| Size of Object | Tablet: φ5-12mm Capsule: 00#-5# all kinds of soft capsule |
| Size of bottles | 20-300ml |
| The diameter for bottles mouth | 20-80mm |
| Output | 4,000pcs/min | 6,000pcs/min | 8,000pcs/min | 10,000pcs/min |
| Capacity | 40bottles/min | 60bottles/min | 80bottle/min | 100bottles/min |
| Power | 0.9KW | 0.9KW | 1.35KW | 1.35KW |
| Power supply | 220V 60HZ |
| Air pressure | 6kgs/c |
| Overall dimensions(mm) | 1700×1700×1900 | 2000×1700×1900 | 2800×1700×1900 | 3200×1700×1900 |
