Fully Automatic Aluminum Plastic Blister Packing Machine CE GMP And
FDA Approved
Application:
The machine is assembled with three parts and can be packed and
transported separately. Under control of PLC, the machine can
complete separately all procedures including warm-up, blister
forming, automatic feeding, heat sealing and synchronous adjustment
of Aluminum-Plastic strip, empty-detecting, hard Aluminum forming,
second heat sealing, batch number printing, blanking and
scrap-collecting, etc.
The machine is suitable for blister packing with Aluminum-Plastic,
Aluminum-Aluminum and Aluminum-Plastic-Aluminum.
Main Technical Data:
| MODEL: | 250A |
| Blanking frequency (cutting): | 15-45 |
| Sheet's quantity of one blanking (sheets): | 1-6(depends to your blister size) |
| Capacity (blisters/min): | 5-400 |
| Adjustable scope of feed travel: (mm) | 10-120 |
| Max Forming depth (mm) PVC: | 270×120×25 |
| Capacity of air compressor(m3/min): | ≥0.36 |
| Power supply (KW): | 220V AC, 50 Hz, Three Phase (Depend on your requirement. |
| Weight (kg): | 1260Kg |
Feature:
l Travel scope can be adjusted.
l Mould is located by locating groove so that it’s easy to change
mould. Adopt the moulds of pressing-and-frothing and cool-forming.
l The material is fed automatically. The mould and feeding equipment
can be designed as user’s requirements.
l Speed is shifted by step-less transducer. Adopt the interface of
human-machine and PLC programmable controller.
l Adopt photoelectric empty-detecting equipment and
waster-eliminating equipment.
l Servo motor drive wheel to grip and tow wrapper, synchronize
accurately. And it will be not waste of time and material for
adjusting when restart the machine.
l The machine equipped Camera Cell for sensor, make the length in an
accurate number.
l The heating moulds will automatically separate when the machine
stops, which contributes to protect the material between them and
extend the machine’s life.
Q: What price terms you offer?
A: We can offer FOB, FCA, CFR, CIF, EXW and other price terms based
on your request.
Q: What payment terms you take?
A: TT, LC, other terms are also workable.
Q: Will you help with installation and stuff training?
A: Yes, we can send our engineers to your place to guide the
installation and train your workers if you need, but the buyer
should bear our technician's round tickets, accomodation, food and
subsidiary USD100/day.
Q: How can I visit your factory?
A: Our factory is located in Ruian city Zhejiang Province. Just let
us know your scheduel in advance and we will arrange everything for
you!
Any other doubts about our machine, please feel easy to contact
with us.
