Fully Automatic 2.2kw Butter Packing Machine 0.6mpa

Ask Lasest Price
Brand Name :	LTPM CHINA
Model Number :	DPP-Series
Certification :	CE
Price :	26800
Payment Terms :	L/C, D/A, D/P, T/T
Supply Ability :	25 SETS Per month
Delivery Time :	25days

Add to Cart

Product Details
Company Profile

Fully Automatic 2.2kw Butter Packing Machine 0.6mpa

Application:

The biggest characteristic of this equipment is using mold positioning design, convenient for customers to replace the mold, reduce debugging time and material cost, the key parts are made of high quality stainless steel and high-grade Aluminum Alloy materials by machining center (CNC), mirror line cutting and other high precision CNC equipment into one processing type, retain the original texture finishing, highlight the noble quality. The transparent protective cover of fine workmanship arc to ensure the safety and the drawing processing of stainless steel cover operation add unlimited style for the overall design, the mechanical products can also bloom artistic charm, the whole process of the details of the pursuit of perfection concept throughout the design and production.

Performance And Characteristics:

1. The whole machine can be divided into packaging to enter the 2.2 meter elevator and split purification workshop.

2. The key components are all made of high quality stainless steel and high-grade aluminum alloy material.

3. Novel mold positioning device, It is very convenient to replace the mold with the positioning mold and the whole guide rail ,to meet the general requirements of quick mold change.

4. For an independent station make indentation and batch number separation, so as to ensure the clarity of the indentation and printing (indentation and batch number can also be in a position).

5.The transmission of the machine is isolated from the work area to prevent pollution and facilitate cleaning.

6. The material feeding is controlled by the precision servo motor, the synchronous precision and the length of the stroke are randomly set by the man-machine interface.

7.The heat sealing cylinder is placed under the heat sealing station to reduce machine center, enhance the running stability of the equipment.For the region and the transmission mechanism is completely isolated to prevent pollution, easy to clean up.

8. Aluminum / plastic (hot forming) and aluminum / aluminum (cold forming) General Institutions: Aluminum/Aluminum packing just change the mold and corresponding feeder is OK.

Specifications:

DPP Automatic Blister Packaging Machine
	DPP-80	DPP-140	DPP-250
Blanking frequency	PVC-AL: 10-40 times/min AL-AL: 10-30 times/min	PVC-AL: 10-40 times/min AL-AL: 10-30 times/min	PVC-AL: 10-40 times/min AL-AL: 10-30 times/min
Adjustable scope of feed travel	30-100mm(adjustable)	30-120mm(adjustable)	30-140mm(adjustable)
The max forming area and depth	120mm×90mm×20mm	150mm×120mm×26mm	240mm×130mm×26mm
Wrapper: ALU	Length: 130mm, thickness: 0.02-0.035mm	Length: 160mm, thickness: 0.02-0.035mm	Length: 250mm, thickness: 0.02-0.035mm
Wrapper: PVC	Length: 130mm, thickness: 0.25-0.5mm	Length: 160mm, thickness: 0.25-0.5mm	Length: 250mm, thickness: 0.25-0.5mm
Wrapper: PTP	Length: 130mm, thickness: 0.02-0.035mm	Length: 160mm, thickness: 0.02-0.035mm	Length: 250mm, thickness: 0.02-0.035mm
Wrapper:Dialysis paper	Length:130mm, specification:50-100 gram	Length:160mm, specification:50-100 gram	Length:250mm, specification:50-100 gram
Power of forming heating	1.5KW	2.4KW	3KW
Power of sealing heating	1.5KW	2.4KW	3KW
Main motor power	0.75KW	1.5KW	1.5KW
Machine Voltage	380V/220V 50Hz
Capacity of air compressor	≥0.2m3/min Pressure: 0.4～0.6MPa	≥0.2m3/min Pressure: 0.5～0.7MPa	≥0.2m3/min Pressure: 0.5～0.7MPa
Overall dimension	2070mm×650mm×1060mm	2350×580×1500 mm	3100×670×1650mm
Weight	560Kg	800KG	1500KG
