Applications
DPP-260SN Aluminum Plastic/duralumin Packing Machine with advanced
performance, simple operation, high output is the latest improved
equipment in our company. It is the best ideal packing equipment
for large and medium-sized pharmaceutical plant, health care
factory and food industry.
Features:
* Adopts top brand PLC controller with touch screen displayed in
Chinese and English, Frequency inverter for speed control, servo
traction, which can ensure the length of blister traction
adjustable within the range.
* With thermal temperature control and test, main machine over
loading protect, PVC and PTP packing material position test, feeder
material position test ,failure automatic debug and alarm,
automatic protection and stop running.
* The machine station module type design of level frame, good
sight, safe and convenient operation.
* Thermal with contact type, positive press formed, air cushion
thermal seal upper and lower net, photo register make your product
package better.
* PVC exchange support with bigger type material support, whole
roller, which makes the equipment more practicability.
* The special design of moulds in rectangle shape, ladder type
fixing, provide much convenience and easy to moulds replacement.
All material contact parts adopt high quality stainless steel and
aluminum metal, slap-up surface treatment craft.
* Discharging finished product in right order, automatic collection
of bad products, auto rewinding of strap material to ensure easy
collection.
* Feeding efficiently, reliable and suitable for many kinds type
arrange and irregular feeding,(according to actual product design
fit feeder)
* The machine has been designed into separated body, which is
easily move into lifts or workshops.
Main Technical Parameter
| Punching Frequency | AL/Plastic :20-60 times/min | AL/AL :15-30 times/min |
| Max. Forming Depth: | AL/Plastic :22mm | AL/AL :18mm |
| Adjustable scope of travel | 30-120mm ( made to order 30-140mm) |
| Clean compressed air | Pressure :0.6—0.8Mpa |
| Air consumption : | ≥0.25m3/min |
| Power | 380V 50HZ 9.6KW |
| Dimension | 4500x760x1620mm |
| Weight | 1800kg |
auto load systerm
