The semi automatic machine, upon demand from the operator, will automatically pick and erect cartons by means of a rotary motion vacuum system; it will then place the open carton into the continuously moving flighted chains

The flaps are then formed on the non-load side and folded open on the load side for the operator to easily insert the product. After loading, glue is applied to the bottom major flaps on both sides, the top and bottom flaps are then brought together automatically to ensure a fully closed and securely sealed carton. The cartons are discharged from the cartoner by powered side belts.

Features:

1.Heavy Welded Steel Box section Frame, Shafts and guides are constructed from Stainless Steel, designed for three-shift operation

2.Extensive, variable speed range subject to size and board quality

3.Size range variable, large carton size range, No change parts

4.Quick size change, all change over points fitted with quick release and digital readouts for

5.easy change over

6.Loading station fitted with overload protection

7.Built in the UK to CE Requirements

Optional Extras

1.Coding (Emboss/Ink/Laser)

2.Stainless steel guards

3.Automatic carton magazine loader

4.3 or 4 arm rotary head

5.Closure, Cold Glue / Tuck type closure

6.Barcode scanning

7.Through conveyor

8.Open flap detection/rejection

Detail

Product Parameters:

Service Center All Over world:

Headquarter China: LTPM CHINA

Add:28th,Jiuan Rd,Jiuli Industrial Zone,Shangwang. Ruian city,Zhejiang,CHINA

America:
Exclusive Agent and Service center in USA:
JRH Pharma R&D Services
River Falls, WI,USA

Pakistan:
Multi Link
Add.:Karachi
Raki Trader
Add.: Lahore
Philippines:
Payo Manufacturing
Add: Davao
Colombia:
LTPM Colombia
Add: Bogota
Latino America:
LTPM Dominican Republic
Add: Domican republic

Our company is recognized as a major pharmaceutical equipment manufacturer and a distributor of packaging materials and pharmaceutical chemicals. Our company is founded in Rui'an, China, with 18 years' (Opened on 1996 year) experience in pharmaceutical industry. This allows us to expand our business in a well-planned manner. We now offer a comprehensive whole production line of quality pharmaceutical machines,packing materials and APIs at competitive prices. Our main products includes:
Fluid Bed Dryer
Spray Drying Machine
Powder Mixing Machine
Granulating Machine
Capsule filling machine
Blister Packing Machine
Cartoning machine
Tablet Pressing Machine
Bottling Machinery
Liquid Production Line
All kinds of lamination films for pharma packaging
Several kinds of APIs

Our Faith: Your Best Pharmaceutical Production Solution!

We offer whole pharmaceutical Production solutions from raw material processing to finished products. We manufacture and distribute different pharmaceutical machinery,packing materials and APIs with our own engineering teams and after-sales service teams.

Based on our experienced engineering team, we produce top quality machines, paking materials and APIs and also help customers select the best quality suppliers. Our company is a technology-driven company and focuses on producing high quality machinery. We employ 15 engineers on machinery design and technology improvement. Each engineer has at least ten years' machining and packaging area experience. We are your extra technical consultant center.

Quality Control:
Our company owns a quality control department to verify each product at different phases, from the procurement of parts to finished products. In order to offer clients the best quality products, we manufacture products in accordance with international standards, such as FDA, GMP and cGMP.

We are your best pharmaceutical production solution!
