    25mm Automatic Labelling Machine MT 130D Beer Bottle Labeling Machine

    Ask Lasest Price
    Brand Name : LTPM China
    Model Number : MT-Series
    Certification : CE, GMP
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 25sets/month
    Delivery Time : 25days
    • Product Details
    • Company Profile

    25mm Automatic Labelling Machine MT 130D Beer Bottle Labeling Machine

    Product Overview

    It can be used to label all kinds of card pouch, anti-static bag and paper piece. It is suitable for unfolded carton labeling. The labeling precision is stable, the press roller is used to caress the workpiece, the transportation is stable, no warping, and the labeling precision is guaranteed.


    Specification:

    Adopting Germany SIEMENS PLC control

    Adopting easy operation large touch screen

    Adopting Germany label sensor

    Adopting Japanese object sensor

    All machines are made of SS#304 The machine can be equipped with coding machine (optional)


    Features:

    The machine is made in SUS304 stainless steel and high grade aluminum alloy.

    Imported step motor or servo motor is used for the labeling head to assure labeling speed and accuracy.

    The photo electricity and control system apply advanced component from Germany or Japan or Taiwan.

    Use PLC man-machine interface control system, which is easy to understand.


    Technical Parameters:

    ModelMT-130D
    The standard systemStep Motor
    Capacity20-130 carton/min
    Operating DirectionLeft or right
    Label speed≤35 m/min
    Tags volume inner diameter76 mm
    Tags volume outer diameter350 mm (max)
    Label SpecificationsGlassine backing Paper , opaque label (The application of carton Can be customized according to customer’s demand)
    Labeling accuracy±1.0mm (subject to the roughness of the plane)
    Weight200KGS
    Total motor power800W
    Power supplyAC220V 50/60HZ Single phase
    Size appearance (mm)2200 (L) 1800 (W) 1500(H)
