Generally Description:
This in-line hot melt glue labeler provides stable labeling
performance. Speed up to 6000 - 7000 bottles per hour, and easy
change parts for variety of specifications. Suitable for OPP
labels, on PET, HDPE round bottles. No glue jam as other spray
system, the machine use easier glue-trans system and label cutting
device, which makes the machine working stable and with good price.
Features:
Cost saving and environment protection
Servo system with high precision
Vacuum system without friction and static
Bottle feed-in smoothly by conveyor
Easy to operate with HMI friendly
Labeling system adopt wheeling design
Automatic pushing bottle system is convenient for bottle feed
in-out
Labeling speed up to 100 BPM
Sensor checking system for bottle without labeling(Optional)
Structure and performance specification:
◆ Wide application range, apply for
Flat/Oval/Square/Rectangular/Round bottles, 2 sides labeling or
just 1 side labeling,easy to switch labeling between bottles, easy
to adjust;
◆ Good quality of labeling,smooth labeling without puckering;
◆ Excellent labeling quality, adopting elastic pressure-coated
belt, flat labeling, no wrinkles, and improve packaging quality;
◆ Flexible application, bottle standing labeling, automatic bottle
splitting function, can be produced in a single machine, or can be
connected to the production line;
◆ Intelligent control, automatic photoelectric tracking, with no
material and no labeling, no automatic calibration and automatic
label detection to prevent leakage and label waste;
◆ High stability, Panasonic PLC + Panasonic touch screen +
Panasonic needle-shaped electric eye + German labor test label
electric eye composed of advanced electronic control system,
support equipment 7 × 24 hours of operation;
◆ Simple adjustment, labeling speed, conveying speed and bottle
dividing speed can realize stepless speed regulation and adjust
according to need;
◆ Rugged and durable, adopting three-bar adjustment mechanism to
make full use of the stability of the triangle, the whole machine
is solid and durable. Made of stainless steel and high-grade
aluminum alloy, in line with GMP
Specifications:
| Production | 300-600 bottles/min |
| Labeling speed | ≤40m/min |
| Labeling accuracy | ±1mm |
| The application specification of label graze paper | Opaque label |
| The application of bottle | Outer diameter 10-24mm Height 25-95mm |
| The application of label | Width 20-70mm Length 25-80mm |
| The inner diameter of label volume | 76mm |
| The outer diameter of label volume | Max. 350mm |
| Driving mode | Servo motor |
| The power of motor | 1000w |
| Size appearance | 2780×1270×1500mm |
| Weight | 300kg |
| Voltage | AC 220V 50/60Hz Single phase (according to the voltage in client
country) |
| Labeling methods | The bottle is stand into, stand paste, stand out |
