Describe:
can suitable for round bottles
1.This kind labeling machine can be suitable for round bottles.
2. Its features simple structure and operation, attaching accuracy
,reliable property, small power and no noise.
3.The whole machine adopts mature PLC control system to ensure the
stable running in high speed; Touch screen makes easy reading and
excellent looking. More than 10 groups of labeling parameters
saved, makes setting rapidly,bottles at the same time.
4. Labeling is performed smoothly with no creases with the use of
elastic cotton idler wheel;
5. Automatic photoelectric detection functions including canceling
labeling without objects there and stopping running or raising an
alarm without labels to use to avoid omitting or wasting labels.
Application:
Feature
1) Control system: Use SIEMENS brand PLC control system, with high
stable operation and extremely low failure rate.
2) Operation system: The man machine control 7 inch touch screen,
directly visual interface easy operation, rich with help function
and fault display function.
3) Check system: Use German LEUZE check label sensor, automatic
check label station, stable and convenient don't have much higher
requirement for worker.
4) Send label system: German Avery labeling engine control system,
stable with high speed.
5) Alarm function: Such as label spill, label broken or other
malfunction during machine working all will alarm and stop working.
6) Machine Material: Machine and spare parts all use material S304
stainless steel and anodized senior aluminum alloy,with high
corrosion resistance and never rust.
7) Low voltage circuit all use the German Schneider brand.
Details:
1.Touch screen
High definition touch screen can set various parameters according
to the demand.
2.Elastic track
With elastic track,the label is smooth and wrinkle free,and the
product quality is improved.
3.Adjusting wheel
The width can be adjusted freely according to the diameter of the
bottle body.
4.Bottle splitting device
Automatic separation of bottles at equal distance to ensure the
stability of subsequent labeling.
5.Detecting system
Automatic detection of label delivery status to ensure unuterruted
production.
6.Spee d regulator
The labeling speed can be adjusted according to the actual need,and
the operation is simple.
Specifications:
| The standard system | Servo Motor |
| Capacity | 20-130 carton/min |
| Operating Direction | Left or right |
| Label speed | ≤35 m/min |
| Tags volume inner diameter | 76 mm |
| Tags volume outer diameter | 350 mm (max) |
| Label Specifications | Glassine backing Paper , opaque label (The application of carton
Can be customized according to customer’s demand) |
| Labeling accuracy | ±1.0mm (subject to the roughness of the plane) |
| Weight | 200KGS |
| Total motor power | 800W |
| Power supply | AC220V 50/60HZ Single phase |
| Size appearance (mm) | 2200 (L) 1800 (W) 1500(H) |
