    DXD Vertical Premade Bag Packing Machine Pillow 260mm

    Ask Lasest Price
    Brand Name : LTPM CHINA
    Model Number : DXD-Series
    Certification : CE, GMP, SGS, BV
    Price : Negotiation
    Payment Terms : L/C, D/A, D/P, T/T, MoneyGram
    Supply Ability : 45 sets/month
    Delivery Time : 25 days
    • Product Details
    • Company Profile

    DXD Vertical Premade Bag Packing Machine Pillow 260mm

    Application

    This machine is suitable for automatic packaging of liquid of foods,medicine and chemicals,

    such as pesticide,shampoo,body foam bath lotion,facial cream,ingredient oil,fruit sauce,

    tomato ketchup and honey etc.


    Machine features

    1. This machine can finish : forming bag--measuring--material filling—sealing—counting—date code printing, all the work automatically;

    2. Photoelectric and tracing system or computer system can be provided without your specific requirements.

    3. The PLC controller has the advantages such as setting the length of the bag; the out put alarm and the speed and quantity with buttons;

    4. This machine can be installed to code printer for 1-3 lines characters such as production and expiry date according to your special request.


    Technical Parameters

    Items / Model
    DXD-350K
    DXD-500K
    DXD-900K
    Pouch length
    50-250mm(L) (adjustable)
    50~160mm
    50~120mm( Pouch length can change)
    Pouch width
    50-85mm(W)
    50~105mm
    50~105mm
    Packing speed
    30-50times/min depend on pouch size and material
    20~50times/nim(depend on pouch size and material)
    80times/nim(depend on pouch size & material)
    Measuring range
    1-50ml
    1~80ml
    1~80ml
    Applicable film
    PET/AL/PE PET/PE NY/AL/PE NY/PE
    PET/AL/PE PET/PE NY/AL/PE NY/PE
    PET/AL/PE PET/PE NY/AL/PE NY/PE
    Max width of film roll
    350mm
    500mm
    900mm
    Max film roll diameter
    300mm
    420mm
    Φ300mm
    Film roll core diameter
    75mm
    75mm
    Φ75mm
    Power voltage
    220V/ 50HZ(do as customer’s request)
    380V50Hz 3P 4W
    380V 50Hz (do as customer's request)
    Power
    5.5kw
    12 Kw
    12 Kw
    Gross Weight
    650kg
    1200kg
    1200kg
    Package size
    (L)1400mm×(W)1000mm×(H)1700mm
    1680x1280x2050mm
    1500x1540x2200mm(L x W x H)

    Working process

    1. Turn on the machine waiting the temperature to setting numerical vaule, and set the parameter on the touch screen.

    2. Put the material to the hopper.

    3. Set the Packaging film to packing machine and test the packing machine working.

    4. Automatic auger measuring material and auto bagging
    5. Bag former auto bag making, the bag automatic sealing.
    6. After bag sealing,finished product will auto cutting by cutting device, finished product put out.


    About Machine's Detail
